Orbital Layouts and Mobile Bliss: Refactoring the Projects Component

Let's talk about crafting a visually engaging and responsive project display. Our team recently tackled a refactor of the Projects component in the rivuz-react project, aiming for an orbital layout and enhanced mobile experience.

The Vision

The goal was to move beyond a standard grid layout and create a more dynamic, circular arrangement of project cards. This would provide a unique visual signature while ensuring a smooth transition to mobile devices.

The Orbital Display

Achieving the orbital effect involved some CSS trickery, using positioning and transformations to place project cards around a central point. The key was to calculate the correct angle and distance for each card to maintain a balanced and aesthetically pleasing arrangement.

Here's a simplified example of how the positioning might look:

.project-container {
  position: relative;
  width: 300px;
  height: 300px;
}

.project-card {
  position: absolute;
  top: 50%;
  left: 50%;
  transform: translate(-50%, -50%); /* Center the card */
}

.project-card:nth-child(1) {
  transform: translate(-50%, -50%) rotate(0deg) translate(150px); /* Positioned along the orbit */
}

.project-card:nth-child(2) {
  transform: translate(-50%, -50%) rotate(72deg) translate(150px); /* Evenly spaced around the circle */
}

/* ... more card positioning ... */

Mobile Enhancement

On smaller screens, the orbital layout could become cramped and unusable. The solution was to implement a media query that would switch to a more traditional, vertically stacked layout for mobile devices. This ensured that the project cards remained easily accessible and readable on any screen size.

@media (max-width: 768px) {
  .project-container {
    width: 100%;
    height: auto;
  }

  .project-card {
    position: relative; /* Revert to standard document flow */
    transform: none; /* Remove orbital positioning */
    margin-bottom: 20px; /* Add spacing between cards */
  }
}

The Takeaway

Don't be afraid to experiment with unconventional layouts to create a unique user experience. Remember to always consider mobile responsiveness and provide a fallback for smaller screens. Test your layout on various devices to ensure it remains usable and visually appealing, no matter the screen size.
